VSI series high efficiency vertical shaft impact crusher(sand maker)is the stone crushing equipment with domestic and international advanced technologies, which is researched on the basis of Germany advanced technology, combining the actual demand of China sand—making industry. It can supply high quality sand aggregate for high building, expressway (railway) construction, municipal engineering, large scale irrigation establishment, concrete batching plant and many other areas.
high efficiency and low consumption;
easy to maintain;
focusing on environmental protection.
VSI Series Sand Making Machine
READ MORE| Model | VSI 7611 | VSI 8518 | VSI 9526 | VSI 1140 | VSI 1145 | VSI 1150 | |
| Capacity (t/h) |
Feed both at center and sides | 80-180 | 140-260 | 200-380 | 300-520 | 350-610 | 360-650 |
| Feed at center | 40-90 | 70-130 | 100-190 | 160-260 | 180-355 | 190-365 | |
| Max.feeding size （mm） |
Soft material | 35 | 40 | 45 | 50 | 50 | 50 |
| Hard material | 30 | 35 | 40 | 40 | 45 | 45 | |
| Rotation speed（r/min） | 1700-1890 | 1520-1690 | 1360-1510 | 1150-1300 | 1150-1300 | 1150-1300 | |
| Motor power（kw） | 4P 110 | 4P 180 | 4P 264 | 4P 400 | 4P 440 | 4P 500 | |
| Overall dimension（L×W×H）（mm） | 4100×2250×2300 | 4160×2320×2900 | 4560×2450×2830 | 5500×2700×3100 | 5500×2700×3100 | 5500×2700×3100 | |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
The VSIA7 series impact sand maker with deep cavity is a new generation product that not only draws on the advanced technology of similar products at home and abroad, but also has a number of independent research and development results.
The HVI series sand maker is a new generation of products that our company introduces German technology, absorbs the domestic and foreign similar products' advanced technology development, and has many spontaneous R & D characteristics at the same time, which integrates all kinds of crushing modes,become the core equipment of mechanism sand industry.
