HLMC series line jet off-line pulse dust collector is a new and efficient bag dust collector developed on the basis of conventional pulse bag dust collector.
HLMC line jet off-line pulse dust collector is serving casting, metallurgy, machinery, electric power, building materials, mining, cement, chemical industry and other industries with its excellent performance. It is suitable for integrated dust collection with large air volume, high dust concentration and limited site, such as: sand making building and sand making line site compact occasions.
HLMC Series Line Spray Off-line Pulse Dust Collector
READ MORE| Model |
Processing air volume (m³/h) |
filtration velocity (m/min) |
Total filtering area (m²) |
Net filtering area (m²) |
Dust concentration of imported air (g/Nm³) |
Dust concentration of outlet air (g/Nm³) |
Clean compressed air | |
| Pressure (Pa) | Air consumption(Nm³/min) | |||||||
| HLMC1000 | 48000~120000 | 0.8~2.0 | 1100 | 1000 | <1000 | <0.02 | (5~7) x 105; | 2.1 |
| HLMC1400 | 67200~168000 | 1500 | 1400 | <1000 | <0.02 | 2.1 | ||
| HLMC1700 | 81600~204000 | 1820 | 1700 | <1000 | <0.02 | 3 | ||
| HLMC2100 | 100800~252000 | 2280 | 2100 | <1000 | <0.02 | 3 | ||
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
