SC/H800i Series Single Cylinder Hydraulic Cone Crushers

Fill out the form below to leave a message, and get our latest special offer instantly

Message

You e-mail address(Required)

Your Phone or Whatsapp

Feature

SC/H800i series single cylinder cone crusher of Hongxing Group is a new generation product comprehensively upgraded on the basis of SC series cone crusher according to market demand and focusing on the forefront of the times. While inheriting many advantages of SC series, this series crusher adopts a cavity design with larger eccentricity, higher rotating speed and larger crushing ratio, so as to improve throughput and yield and reduce equipment energy consumption. The equipment incorporates the most advanced Internet concept: all-weather connectivity to the Internet of Things platform, effectively improving productivity, predicting performance, and maximizing the uptime of the equipment.

Advantage

  • The industrial Internet of Things platform can be used to access

    crusher production data all weather, predictive maintenance of equipment and improve equipment utilization;

  • The upper and lower frame body and the main shaft are reinforced

    to greatly improve the reliability of the equipment;

  • Standard off-line filtration system

    can ensure all-weather lubricating oil filtration, reduce the internal wear of crusher parts, extend the service life of lubricating oil up to 5 times;

  • The new intelligent system

    can track all operational data, optimize parameters, deal with faults, and quickly complete maintenance.

Technical Specifications

SC/H800i Series Single Cylinder Hydraulic Cone Crushers

READ MORE
  • SC/H800i Series Single Cylinder Hydraulic Cone Crushers
Model Cavities Feeding Size
(mm)
Maximum Feeding Size
(mm)
Minimum Discharging Size
(mm)
Processing Capacity
(t/h)
Power
(kw)
SC840i C1 431 345 25 230-659 315
C2 345 275 22 212-645
SH830i F1 211 169 13 113-283 250
F2 93 74 8 84-212
F3 61 49 5 61-139
SH840i F1 250 200 16 162-371 315
F2 159 127 16 187-406
F3 73 58 10 126-232
SH860i F1 315 252 16 259-799 500
F2 169 135 16 281-867
SH865i F3 85 68 10 179-468
SH870i F1 350 280 25 392-1173 630
F2 184 147 19 351-1195
F3 99 79 13 236-747
SH890i F1 428 342 25 488-1670 800
F2 302 242 22 524-1789
F3 219 175 19 460-1677
SH895i F4 112 90 13 291-910
F5 89 71 10 258-839

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
